Thông số kỹ thuật:
| Outline | |
| Mixing capability | |
| On-board processors: | SPX algorithm: 24 programs, PARAMETER control:1, FOOT SW:1 (FX RTN CH on/off) |
|
I/O |
|
| Phantom power: | +48 V |
| Digital I/O: | USB Audio Class 2.0 compliant Sampling Frequency: Max 192 kHz, Bit Depth: 24-bit |
|
Input Channels |
|
| Mono[MIC/LINE]: | 4 |
| Mono/Stereo[MIC/LINE]: | 2 |
| Stereo[LINE]: | 2 |
| Output Channels | |
| STEREO OUT: | 2 |
| MONITOR OUT: | 1 |
| PHONES: | 1 |
| AUX SEND: | 2 |
| GROUP OUT: | 2 |
| Bus: | Stereo: 1, GROUP: 2, AUX: 2 (incl. FX) |
|
Input Channel Function |
|
| PAD: | 26 dB (Mono) |
| HPF: | 80 Hz, 12 dB/oct (Mono/Stereo: MIC only) |
| COMP: | 1-knob compressor (Gain/Threshold/Ratio) Threshold: +22 dBu to -8 dBu, Ratio: 1:1 to 4:1, Output level: 0 dB to 7 dB Attack time: approx. 25 msec, Release time: approx. 300 msec |
| EQ HIGH: | Gain: +15 dB/-15 dB, Frequency: 10 kHz shelving |
| EQ MID: | Gain: +15 dB/-15 dB, Frequency: 2.5 kHz peaking |
| EQ LOW: | Gain: +15 dB/-15 dB, Frequency: 100 Hz shelving |
| PEAK LED: | LED turns on when post EQ signal reaches 3 dB below clipping |
| Level Meter: | 2x12 -segment LED meter [PEAK, +10, +6, +3, 0, -3, -6, -10, -15, -20, -25, -30 dB] |
| Total harmonic distortion: | 0.03 % @ +14dBu (20 Hz to 20kHz), GAIN knob: Min, 0.005 % @ +24dBu (1kHz), GAIN knob: Min |
| Frequency response: | +0.5 dB/-1.5 dB (20 Hz to 48 kHz) , refer to the nominal output level @ 1 kHz, GAIN knob: Min |
|
Mức nhiễu & Ồn |
|
| Nhiễu đầu vào tương đương: | -128 dBu (Mono Input Channel, Rs: 150Ω, GAIN knob: Max) |
| Nhiễu đầu ra thặng dư: | -102 dBu (STEREO OUT, STEREO master fader: Min) |
| Crosstalk: | -78 dB |
| Power requirements: | AC 100 – 240 V, 50 / 60 Hz |
| Power consumption: | 22 W |
| Accessories: | Included Accessory: Owner’s Manual, Technical Specifications, AC power cord, Cubase AI Download Information, Optional Accessory: Rack-mount kit RK-MG12, Foot Switch FC5 |
| Others: | Operating Temperature: 0 to +40˚C |
