| D.I / Instrument Input |
- RANGE:40dB
- LINEUP:12dBu = 0dBFS
- THD+N @ 0dBu:0.1%
- SNR:100dBu A-Weighted
- FREQUENCY RESPONSE – MIN GAIN:±0.5dB 10Hz to 20kHz
- 1/4” TS JACK:Tip (Hot) & Sleeve (Shield)
|
| Microphone Preamplifier |
- GAIN RANGE: 58dB
- LINEUP:12dBu = 0dBFS
- MIC MAX INPUT LEVEL:12dBu
- MAX INPUT LEVEL:21dBu
- INPUT IMPEDANCE (Mic):2.8k
- INPUT IMPEDANCE (Line):>8k
- THD+N @ 0dBu:0.00170%
- THD+N @ 0dBu MAX GAIN:<0.04%
- SNR:101dBu A-Weighted
- EIN:129dB A-Weighted
- CMRR @ 1k:>75dB
- CROSSTALK:>-100dB
- FREQUENCY RESPONSE – MIN GAIN:±0.5dB 10Hz to 40kHz
- XLR COMBI FEMALE:Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
- 1/4” TRS JACK:Tip (Hot), Ring (Cold) & Sleeve (Shield)
|
| Analogue to Digital Converter |
- THD+N @ -1dBFS:0.001%
- DYNAMIC RANGE:120dB A-Weighted
- CMRR:>80dB
- FREQUENCY RESPONSE:±0.5dB 10Hz to 40kHz
- Line Outputs (DAC)
- LINEUP:12dBu = 0dBFS
- THD+N @ -1dBFS:0.0006%
- DYNAMIC RANGE:125.5dB A-Weighted
- CROSSTALK:>120dB
- FREQUENCY RESPONSE:±0.1dB 10Hz to 40kHz
- 1/4” TRS JACK:Tip (Hot), Ring (Cold) & Sleeve (Shield)
|
| Headphone Outputs |
- LINEUP:18dBu = 0dBFS
- THD+N @ -1dBFS:0.0009%
- DYNAMIC RANGE:125.5dB A-Weighted
- CROSSTALK:>116dB
- FREQUENCY RESPONSE:±0.25dB 10Hz to 40kHz
- MAXIMUM LEVEL @ 30R:2.59V Peak, 1.827V RMS, 223mW
- MAXIMUM LEVEL @ 62R:4.18V Peak, 2.95V RMS, 280mW
- MAXIMUM LEVEL @ 600R:7.72V Peak, 5.46V RMS, 100mW
- 1/4” TRS JACK:Tip (Left), Ring (Right) & Sleeve (Shield)
|
USB-C High Speed
|
BUS POWER:
- MIN REQUIREMENT:0.9A @ 5V >=USB 3.0 Port
- MAX REQUIREMENT:1.5A @ 5V USB-C: Provides higher headphone outputs levels
- No. of INPUT CHANNELS:10
- No. of OUTPUT CHANNELS:6
- DSP MIXER LATENCY ROUND TRIP (in-to-out):44.1kHz 0.65mS
- DSP MIXER LATENCY ROUND TRIP (in-to-out):48.0kHz 0.6mS
- DSP MIXER LATENCY ROUND TRIP (in-to-out):88.2kHz 0.33mS
- DSP MIXER LATENCY ROUND TRIP (in-to-out):96.0kHz 0.31mS
|
